09675096758
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09675096758 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 09675096758 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 09675096758 |
|---|---|
| Manufacturer | HARTING |
| Description | CONN D-SUB RCPT 9POS R/A SOLDER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $9.331 | $8.424 | $8.071 | $7.567 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $7.314 | $6.911 | $6.709 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 09675096758 | Manufacturer | HARTING |
|---|---|---|---|
| Description | CONN D-SUB RCPT 9POS R/A SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4874 pcs | Data sheet | 09675096758 Drawing |
| Category | Connectors, Interconnects | Wire Gauge | - |
| Voltage Rating | - | Termination | Solder |
| Shell Size, Connector Layout | 1 (DE, E) | Shell Material, Finish | Brass, Tin Plated |
| Series | - | Packaging | Bulk |
| Other Names | 1195-2780 9675096758 |
Operating Temperature | -25°C ~ 70°C |
| Number of Rows | 2 | Number of Positions | 9 |
| Mounting Type | Panel Mount, Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | IP67 - Dust Tight, Waterproof |
| Housing Material | Thermoplastic, Glass Filled | Flange Feature | Housing/Shell (4-40) |
| Features | Board Lock | Detailed Description | 9 Position D-Sub Receptacle, Female Sockets Connector |
| Current Rating | - | Contact Type | Signal |
| Contact Material | - | Contact Form | - |
| Contact Finish Thickness | 30.0µin (0.76µm) | Contact Finish | Gold or Gold-Palladium |
| Connector Type | Receptacle, Female Sockets | Connector Style | D-Sub |
| Color | - | Backset Spacing | 0.228" (5.80mm) |
