09300102296
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09300102296 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 09300102296 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 09300102296 |
|---|---|
| Manufacturer | HARTING |
| Description | CONN BASE SIDE ENTRY SZ10B PG16 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $24.687 | $23.235 | $22.509 | $21.057 | $19.895 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 09300102296 | Manufacturer | HARTING |
|---|---|---|---|
| Description | CONN BASE SIDE ENTRY SZ10B PG16 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1638 pcs | Data sheet | 09300102296 DrawingHan® Hoods and Housings Catalog |
| Category | Connectors, Interconnects | Thread Size | PG16 |
| Style | Side Entry | Size / Dimension | 3.701" L x 2.047" W x 2.118" H (94.00mm x 52.00mm x 53.80mm) |
| Size | 10B | Series | Han® B |
| Packaging | Bulk | Other Names | 09300102296-ND 1195-4709 |
| Operating Temperature | -40°C ~ 125°C | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 7 Weeks | Lock Location | Locking Clip (1) on Base Bottom |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Housing Material | Aluminum, Die Cast | Housing Finish | Powder Coated |
| Housing Color | Gray | Features | Cover, Feed Through |
| Connector Type | Base - Box Mount |
