09185146323
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09185146323 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 09185146323 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 09185146323 |
|---|---|
| Manufacturer | HARTING |
| Description | CONN HEADER 14POS T/H R/A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $0.783 | $0.71 | $0.667 | $0.638 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $0.609 | $0.551 | $0.507 | $0.435 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 09185146323 | Manufacturer | HARTING |
|---|---|---|---|
| Description | CONN HEADER 14POS T/H R/A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 72082 pcs | Data sheet | 0918564x32x DrawingSEK Series 6-64 Contacts Catalog |
| Category | Connectors, Interconnects | Termination | Solder |
| Stacking Direction | Male Pin | Shrouding | 0.100" (2.54mm) |
| Series | SEK | Row Spacing - Mating | Shrouded |
| RoHS Status | Bulk | Other Names | 1195-1684 9185146323 |
| Number of Rows | 2 | Number of Positions | 14 |
| Mounting Type | Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Insulation | All | Manufacturer Standard Lead Time | 3 Weeks |
| Manufacturer Part Number | 09185146323 | Features | - |
| Expanded Description | 14 Positions Header Connector 0.100" (2.54mm) Through Hole, Right Angle | Description | CONN HEADER 14POS T/H R/A |
| Current - Max/Contact | Latch Holder | Contact Length - Post | 0.242" (6.15mm) |
| Contact Length - Mating | 0.100" (2.54mm) | Contact Finish Thickness - Mating | - |
| Contact Finish - Post | - | Connector Type | Header |
| Actual Diameter | Gray |
