Home > Products > Connectors, Interconnects > Heavy Duty Connectors - Frames > 09142100303

09142100303

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09142100303 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	09142100303
Manufacturer	HARTING
Description	HINGED FRAME HMC 10B F. 3 MODULE
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	50 pcs	100 pcs	250 pcs
~~In Stock~~ 4959 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs
	$10.774	$9.724	$9.317
	$8.735	$8.443	$7.978

Product parameter
Data sheet

Product parameter

Part Number	09142100303	Manufacturer	HARTING
Description	HINGED FRAME HMC 10B F. 3 MODULE	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4959 pcs	Data sheet	09142100303 Drawing
Category	Connectors, Interconnects	Size	10B
Series	Han-Modular®	Packaging	Bulk
Other Names	1195-4046	Operating Temperature	-40°C ~ 125°C
Number of Modules	3	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material	Zinc Plate	Manufacturer Standard Lead Time	8 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Includes	5 pcs - 1 Frame, 4 Screws
Gender	Female/Male	Frame Type	Retaining Frame, Hinged
Color	-
