09140020301
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09140020301 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 09140020301 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 09140020301 |
|---|---|
| Manufacturer | HARTING |
| Description | CONN BASE BOTTOM ENTRY |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $10.89 | $9.83 | $9.418 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $8.829 | $8.535 | $8.064 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 09140020301 | Manufacturer | HARTING |
|---|---|---|---|
| Description | CONN BASE BOTTOM ENTRY | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4490 pcs | Data sheet | 09140020301 Drawing |
| Category | Connectors, Interconnects | Thread Size | - |
| Style | Bottom Entry | Size / Dimension | 2.244" L x 1.535" W x 1.024" H (57.00mm x 39.00mm x 26.00mm) |
| Size | - | Series | Han-Modular® Twin |
| Packaging | Bulk | Other Names | 1195-1464 9140020301 |
| Operating Temperature | -40°C ~ 125°C | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 6 Weeks | Lock Location | Locking Clip (1) on Base Bottom |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Housing Material | Aluminum, Die Cast | Housing Finish | Powder Coated |
| Housing Color | Gray | Features | - |
| Connector Type | Base - Panel Mount |
