Home > Products > Discrete Semiconductor Products > Transistors - IGBTs - Single > GPA040A120L-ND

GPA040A120L-ND

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy GPA040A120L-ND with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	GPA040A120L-ND
Manufacturer	Global Power Technologies Group
Description	IGBT 1200V 80A 455W TO264
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 25554 pcs
Reference Price (In US Dollars)	2500 pcs
Reference Price (In US Dollars)	$1.221

Product parameter
Data sheet

Product parameter

Part Number	GPA040A120L-ND	Manufacturer	Global Power Technologies Group
Description	IGBT 1200V 80A 455W TO264	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	25554 pcs	Data sheet	GPA040A120L-ND
Category	Discrete Semiconductor Products	Voltage - Collector Emitter Breakdown (Max)	1200V
Vce(on) (Max) @ Vge, Ic	2.8V @ 15V, 40A	Test Condition	600V, 40A, 5 Ohm, 15V
Td (on/off) @ 25°C	41ns/200ns	Switching Energy	5.8mJ (on), 1.5mJ (off)
Supplier Device Package	TO-264	Series	-
Reverse Recovery Time (trr)	220ns	Power - Max	455W
Packaging	Tube	Package / Case	TO-264-3, TO-264AA
Other Names	1560-1223-1 1560-1223-1-ND 1560-1223-5	Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Input Type	Standard
IGBT Type	NPT and Trench	Gate Charge	510nC
Detailed Description	IGBT NPT and Trench 1200V 80A 455W Through Hole TO-264	Current - Collector Pulsed (Icm)	120A
Current - Collector (Ic) (Max)	80A
