S12D
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy S12D with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy S12D with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | S12D |
|---|---|
| Manufacturer | GeneSiC Semiconductor |
| Description | DIODE GEN PURP 200V 12A DO4 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 100 pcs | ||||
|---|---|---|---|---|---|
| $1.563 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | S12D | Manufacturer | GeneSiC Semiconductor |
|---|---|---|---|
| Description | DIODE GEN PURP 200V 12A DO4 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 22142 pcs | Data sheet | S12B~S12JRDO-4 (DO-203AA) Pkg Drawing |
| Category | Discrete Semiconductor Products | Voltage - Peak Reverse (Max) | Standard |
| Voltage - Forward (Vf) (Max) @ If | 12A | Voltage - Breakdown | DO-4 |
| Series | - | RoHS Status | Bulk |
| Reverse Recovery Time (trr) | Standard Recovery >500ns, > 200mA (Io) | Resistance @ If, F | - |
| Polarization | DO-203AA, DO-4, Stud | Other Names | 1242-1234 S12DGN S12DGN-ND |
| Mounting Type | Chassis, Stud Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 10 Weeks | Manufacturer Part Number | S12D |
| Expanded Description | Diode Standard 200V 12A Chassis, Stud Mount DO-4 | Diode Configuration | 10µA @ 50V |
| Description | DIODE GEN PURP 200V 12A DO4 | Current - Reverse Leakage @ Vr | 1.1V @ 12A |
| Current - Average Rectified (Io) (per Diode) | 200V | Capacitance @ Vr, F | -65°C ~ 175°C |
