Home > Products > Power Supplies - External/Internal (Off-Board) > LED Drivers > LXD100-2800SW

LXD100-2800SW

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LXD100-2800SW with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	LXD100-2800SW
Manufacturer	Excelsys Technologies Ltd.
Description	LED DRIVER CC AC/DC 22-36V 2.8A
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1439 pcs
Reference Price (In US Dollars)	200 pcs
Reference Price (In US Dollars)	$21.112

Product parameter
Data sheet

Product parameter

Part Number	LXD100-2800SW	Manufacturer	Excelsys Technologies Ltd.
Description	LED DRIVER CC AC/DC 22-36V 2.8A	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1439 pcs	Data sheet	LXD100 Series LED Brochure
Category	Power Supplies - External/Internal (Off-Board)	Weight	2.3 lbs (1kg)
Voltage - Output	22 ~ 36 V	Voltage - Isolation	3.75kV
Voltage - Input (Min)	90VAC	Voltage - Input (Max)	305VAC
Type	Constant Current	Topology	AC DC Converter
Termination Style	Wire Leads	Size / Dimension	8.70" L x 2.66" W x 1.46" H (221.0mm x 67.5mm x 37.0mm)
Series	LXD100	Ratings	IP67
Power (Watts)	100W	Operating Temperature	-35°C ~ 65°C
Number of Outputs	1	Mounting Type	Chassis Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	10 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	OVP, SCP
Efficiency	90%	Dimming	Analog
Detailed Description	2.8A 22 ~ 36 V Constant Current LED Driver AC DC Converter Topology 1 Output	Current - Output (Max)	2.8A
Approvals	CE, cULus, EN
