Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - DC/DC & AC/DC (Off-Line) S > MXL7204EVB

MXL7204EVB

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MXL7204EVB with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MXL7204EVB
Manufacturer	Exar Corporation
Description	EVAL BRD FOR MXL7204
Lead Free Status / RoHS Status

~~In Stock~~ 1913 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$17.228

Product parameter
Data sheet

Product parameter

Part Number	MXL7204EVB	Manufacturer	Exar Corporation
Description	EVAL BRD FOR MXL7204	Lead Free Status / RoHS Status
Quantity Available	1913 pcs	Data sheet	Power Management Brochure MXL7204EVB Manual MXL7204 Datasheet
Category	Development Boards, Kits, Programmers	Voltage - Output	3.3V, 1.8V
Voltage - Input	4.5 V ~ 20 V	Utilized IC / Part	MXL7204
Supplied Contents	Board(s)	Series	-
Regulator Topology	Buck	Outputs and Type	2, Non-Isolated
Other Names	1016-2203	Manufacturer Standard Lead Time	8 Weeks
Main Purpose	DC/DC, Step Down	Frequency - Switching	780kHz
Detailed Description	MXL7204 - DC/DC, Step Down 2, Non-Isolated Outputs Evaluation Board	Current - Output	4A, 4A
Board Type	Fully Populated
