TG-5500CA-09N 20.0000M3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TG-5500CA-09N 20.0000M3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TG-5500CA-09N 20.0000M3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TG-5500CA-09N 20.0000M3 |
|---|---|
| Manufacturer | Epson |
| Description | OSC VCTCXO 20.0000MHZ SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 250 pcs | ||||
|---|---|---|---|---|---|
| $10.597 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | TG-5500CA-09N 20.0000M3 | Manufacturer | Epson |
|---|---|---|---|
| Description | OSC VCTCXO 20.0000MHZ SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3024 pcs | Data sheet | TG-5500CA, 5501CA Series DatasheetProduct Configuration Guide |
| Category | Crystals, Oscillators, Resonators | Voltage - Supply | 2.7 V ~ 5.5 V |
| Type | VCTCXO | Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) |
| Series | TG-5500CA | Ratings | - |
| Packaging | Tape & Reel (TR) | Package / Case | 10-SMD, No Lead |
| Output | Clipped Sine Wave, CMOS | Other Names | TG-5500CA-09N 20.0000M3-ND TG-5500CA-09N20.0000M3 X1G003561001112 |
| Operating Temperature | -40°C ~ 85°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 21 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 0.067" (1.70mm) |
| Function | Enable/Disable | Frequency Stability | ±280ppb |
| Frequency | 20MHz | Detailed Description | 20MHz VCTCXO Clipped Sine Wave, CMOS Oscillator 2.7 V ~ 5.5 V Enable/Disable 10-SMD, No Lead |
| Current - Supply (Max) | 6mA | Current - Supply (Disable) (Max) | - |
| Base Resonator | Crystal | Absolute Pull Range (APR) | - |
