SI8235AB-D-IMR
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SI8235AB-D-IMR with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SI8235AB-D-IMR with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SI8235AB-D-IMR |
|---|---|
| Manufacturer | Energy Micro (Silicon Labs) |
| Description | DGTL ISO 2.5KV GATE DRIVER 14LGA |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 2500 pcs | ||||
|---|---|---|---|---|---|
| $0.737 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SI8235AB-D-IMR | Manufacturer | Energy Micro (Silicon Labs) |
|---|---|---|---|
| Description | DGTL ISO 2.5KV GATE DRIVER 14LGA | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 49900 pcs | Data sheet | SI823x Datasheet |
| Category | Isolators | Voltage - Supply | 6.5 V ~ 24 V |
| Voltage - Isolation | 2500Vrms | Voltage - Forward (Vf) (Typ) | - |
| Technology | Capacitive Coupling | Supplier Device Package | 14-LGA (5x5) |
| Series | Automotive, AEC-Q100 | Rise / Fall Time (Typ) | 12ns, 12ns (Max) |
| Pulse Width Distortion (Max) | 5.6ns | Propagation Delay tpLH / tpHL (Max) | 60ns, 60ns |
| Packaging | Tape & Reel (TR) | Package / Case | 14-VFLGA |
| Other Names | 336-4909-2 SI8235AB-D-IMR-ND |
Operating Temperature | -40°C ~ 125°C |
| Number of Channels | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Manufacturer Standard Lead Time | 6 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Detailed Description | 4A Gate Driver Capacitive Coupling 2500Vrms 2 Channel 14-LGA (5x5) |
| Current - Peak Output | 4A | Current - Output High, Low | 2A, 4A |
| Common Mode Transient Immunity (Min) | 20kV/µs | Approvals | CQC, CSA, UR, VDE |
