Home > Products > Discrete Semiconductor Products > Thyristors - SCRs - Modules > VSKL230-16D25

VSKL230-16D25

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy VSKL230-16D25 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	VSKL230-16D25
Manufacturer	Electro-Films (EFI) / Vishay
Description	SCR 1600-2500V 230A MAGN-A-PAK
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 5570 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter

Product parameter

Part Number	VSKL230-16D25	Manufacturer	Electro-Films (EFI) / Vishay
Description	SCR 1600-2500V 230A MAGN-A-PAK	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	5570 pcs	Data sheet
Category	Discrete Semiconductor Products	Voltage - Off State	1.6kV
Voltage - Gate Trigger (Vgt) (Max)	3V	Structure	Series Connection - SCR/Diode
Series	-	Packaging	Bulk
Package / Case	3-MAGN-A-PAK™	Other Names	*IRKL230-16D25 IRKL230-16D25 IRKL230-16D25-ND
Operating Temperature	-	Number of SCRs, Diodes	1 SCR, 1 Diode
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant	Detailed Description	SCR Module 1.6kV 510A Series Connection - SCR/Diode Chassis Mount 3-MAGN-A-PAK™
Current - On State (It (RMS)) (Max)	510A	Current - On State (It (AV)) (Max)	230A
Current - Non Rep. Surge 50, 60Hz (Itsm)	7500A, 7850A	Current - Hold (Ih) (Max)	500mA
Current - Gate Trigger (Igt) (Max)	200mA	Base Part Number	KL230
