Home > Products > Discrete Semiconductor Products > Transistors - IGBTs - Modules > VS-ETL015Y120H

VS-ETL015Y120H

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy VS-ETL015Y120H with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	VS-ETL015Y120H
Manufacturer	Electro-Films (EFI) / Vishay
Description	IGBT 1200V 22A 89W EMIPAK-2B
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1372 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	100 pcs
Reference Price (In US Dollars)	$30.118	$28.613	$27.86	$25.789

Product parameter
Data sheet

Product parameter

Part Number	VS-ETL015Y120H	Manufacturer	Electro-Films (EFI) / Vishay
Description	IGBT 1200V 22A 89W EMIPAK-2B	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1372 pcs	Data sheet	VS-ETL015Y120H
Category	Discrete Semiconductor Products	Voltage - Collector Emitter Breakdown (Max)	1200V
Vce(on) (Max) @ Vge, Ic	3.03V @ 15V, 15A	Supplier Device Package	EMIPAK-2B
Series	-	Power - Max	89W
Package / Case	EMIPAK-2B	Other Names	VS-ETL015Y120H-ND VS-ETL015Y120HGI VSETL015Y120H
Operating Temperature	150°C (TJ)	NTC Thermistor	Yes
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	45 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Input Capacitance (Cies) @ Vce	1.07nF @ 30V	Input	Standard
IGBT Type	Trench	Detailed Description	IGBT Module Trench 1200V 22A 89W Chassis Mount EMIPAK-2B
Current - Collector Cutoff (Max)	75µA	Current - Collector (Ic) (Max)	22A
