CPV362M4U
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CPV362M4U with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CPV362M4U with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CPV362M4U |
|---|---|
| Manufacturer | Electro-Films (EFI) / Vishay |
| Description | IGBT SIP MODULE 600V 3.9A IMS-2 |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 160 pcs | ||||
|---|---|---|---|---|---|
| $12.529 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | CPV362M4U | Manufacturer | Electro-Films (EFI) / Vishay |
|---|---|---|---|
| Description | IGBT SIP MODULE 600V 3.9A IMS-2 | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 2989 pcs | Data sheet | VS-CPV362M4FPbF |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 600V |
| Vce(on) (Max) @ Vge, Ic | 1.95V @ 15V, 7.2A | Supplier Device Package | IMS-2 |
| Series | - | Power - Max | 23W |
| Package / Case | 19-SIP (13 Leads), IMS-2 | Other Names | *CPV362M4U VS-CPV362M4U VS-CPV362M4U-ND VSCPV362M4U VSCPV362M4U-ND |
| Operating Temperature | -40°C ~ 150°C (TJ) | NTC Thermistor | No |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 21 Weeks | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Input Capacitance (Cies) @ Vce | 0.53nF @ 30V | Input | Standard |
| IGBT Type | - | Detailed Description | IGBT Module Three Phase Inverter 600V 7.2A 23W Through Hole IMS-2 |
| Current - Collector Cutoff (Max) | 250µA | Current - Collector (Ic) (Max) | 7.2A |
| Configuration | Three Phase Inverter | Base Part Number | CPV362M4 |
