409CNQ135
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 409CNQ135 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 409CNQ135 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 409CNQ135 |
|---|---|
| Manufacturer | Electro-Films (EFI) / Vishay |
| Description | DIODE MODULE 135V 200A TO244AB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 409CNQ135 | Manufacturer | Electro-Films (EFI) / Vishay |
|---|---|---|---|
| Description | DIODE MODULE 135V 200A TO244AB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4445 pcs | Data sheet | 409CNQyyy SERIES |
| Category | Discrete Semiconductor Products | Voltage - Forward (Vf) (Max) @ If | 1.03V @ 200A |
| Voltage - DC Reverse (Vr) (Max) | 135V | Supplier Device Package | TO-244AB |
| Speed | Fast Recovery = 200mA (Io) | Series | - |
| Packaging | Bulk | Package / Case | TO-244AB |
| Other Names | *409CNQ135 VS-409CNQ135 VS-409CNQ135-ND VS409CNQ135 VS409CNQ135-ND |
Operating Temperature - Junction | -55°C ~ 175°C |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Diode Type | Schottky |
| Diode Configuration | 1 Pair Common Cathode | Detailed Description | Diode Array 1 Pair Common Cathode Schottky 135V 200A Chassis Mount TO-244AB |
| Current - Reverse Leakage @ Vr | 6mA @ 135V | Current - Average Rectified (Io) (per Diode) | 200A |
| Base Part Number | 409CNQ* |
