Home > Products > Transformers > Current Sense Transformers > B82801A0214A050

B82801A0214A050

B82801A0214A050

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B82801A0214A050 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	B82801A0214A050
Manufacturer	EPCOS
Description	CURR SENSE XFMR 1:50 SMD
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	50 pcs	100 pcs	250 pcs
~~In Stock~~ 39185 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs
	$1.625	$1.318	$1.065
	$0.998	$0.953	$0.925

Product parameter
Data sheet

Product parameter

Part Number	B82801A0214A050	Manufacturer	EPCOS
Description	CURR SENSE XFMR 1:50 SMD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	39185 pcs	Data sheet	B82801A Series
Category	Transformers	Weight	0.006 oz (0.17g)
Type	Invasive	Turns Ratio - Primary:Secondary	1:50
Termination Style	J Lead	Size / Dimension	0.138" L x 0.185" W (3.50mm x 4.70mm)
Series	B82801A	Ratings	-
Packaging	Original-Reel®	Other Names	495-4038-6
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	22 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Inductance	205µH	Height - Seated (Max)	0.138" (3.50mm)
Frequency Range	50kHz ~ 1MHz	Energy Time (E.T.)	-
Detailed Description	1:50 Current Sense Transformer 50kHz ~ 1MHz 2.5 mOhm Primary, 2.2 Ohm Secondary 205µH Surface Mount	DC Resistance (DCR)	2.5 mOhm Primary, 2.2 Ohm Secondary
Current Ratio	-
