B82720S2202N040
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B82720S2202N040 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy B82720S2202N040 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | B82720S2202N040 |
|---|---|
| Manufacturer | EPCOS |
| Description | CMC 1.1MH 2A 2LN SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 250 pcs | 500 pcs | 750 pcs | ||
|---|---|---|---|---|---|
| $0.492 | $0.464 | $0.437 | |||
| 1250 pcs | 2500 pcs | 6250 pcs | |||
| $0.424 | $0.41 | $0.396 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | B82720S2202N040 | Manufacturer | EPCOS |
|---|---|---|---|
| Description | CMC 1.1MH 2A 2LN SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 81434 pcs | Data sheet | B82720S Series |
| Category | Filters | Voltage Rating - DC | - |
| Voltage Rating - AC | 250V | Size / Dimension | 0.571" L x 0.524" W (14.50mm x 13.30mm) |
| Series | B82720 | Ratings | - |
| Packaging | Tape & Reel (TR) | Package / Case | Horizontal, 8 Gull Wing |
| Other Names | 495-5723 495-5723-2 495-5723-ND B82720S2202N 40 B82720S2202N40 B82720S2202N40-ND |
Operating Temperature | -40°C ~ 125°C |
| Number of Lines | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 20 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance @ Frequency | 1.1mH @ 10kHz |
| Height (Max) | 0.421" (10.70mm) | Filter Type | Power Line |
| Features | - | Detailed Description | 1.1mH @ 10kHz 2 Line Common Mode Choke Surface Mount 2A DCR 65 mOhm (Typ) |
| DC Resistance (DCR) (Max) | 65 mOhm (Typ) | Current Rating (Max) | 2A |
| Approvals | - |
