B65813J0000R030
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B65813J0000R030 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy B65813J0000R030 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | B65813J0000R030 |
|---|---|
| Manufacturer | EPCOS |
| Description | FERRITE CORE RM 7.6UH N30 2PCS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 200 pcs | ||||
|---|---|---|---|---|---|
| $0.524 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | B65813J0000R030 | Manufacturer | EPCOS |
|---|---|---|---|
| Description | FERRITE CORE RM 7.6UH N30 2PCS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 74178 pcs | Data sheet | B65813,14, B65679 |
| Category | Magnetics - Transformer, Inductor Components | Width | 13.50mm |
| Tolerance | -20%, +30% | Supplier Device Package | RM 10 |
| Series | B65813 | Other Names | B65813J R 30 B65813JR30 B65813JR30-ND |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Minimum Core Cross Section (Amin) mm² | 90 |
| Material | N30 | Manufacturer Standard Lead Time | 24 Weeks |
| Length | 28.50mm | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Initial Permeability (µi) | 4300 | Inductance Factor (Al) | 7.6µH |
| Height | 9.35mm | Gap | Ungapped |
| Finish | Uncoated | Effective Permeability (µe) | 2720 |
| Effective Magnetic Volume (Ve) mm³ | 4310 | Effective Length (le) mm | 44 |
| Effective Area (Ae) mm² | 98 | Diameter | - |
| Core Type | RM | Core Factor (ΣI/A) mm1 | 0.45 |
