Home > Products > Magnetics - Transformer, Inductor Components > Ferrite Cores > B65517D0063A033

B65517D0063A033

B65517D0063A033

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B65517D0063A033 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	B65517D0063A033
Manufacturer	EPCOS
Description	FERRITE CORE P 63NH M33 2PCS
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 68935 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
	$0.693	$0.597	$0.454	$0.43	$0.382
	$0.358	$0.334	$0.307	$0.298

Product parameter
Data sheet

Product parameter

Part Number	B65517D0063A033	Manufacturer	EPCOS
Description	FERRITE CORE P 63NH M33 2PCS	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	68935 pcs	Data sheet	B65517,18,22,24 Series
Category	Magnetics - Transformer, Inductor Components	Width	-
Tolerance	±3%	Supplier Device Package	P 9 x 5
Series	B65517	Other Names	495-5106 B65517D 63A 33 B65517D63A33 B65517D63A33-ND
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Material	M33
Manufacturer Standard Lead Time	42 Weeks	Length	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Initial Permeability (µi)	750
Inductance Factor (Al)	63nH	Height	2.70mm
Gap	Gapped	Finish	Uncoated
Effective Permeability (µe)	63	Effective Magnetic Volume (Ve) mm³	125
Effective Length (le) mm	12.5	Effective Area (Ae) mm²	10
Diameter	9.30mm	Core Type	P (Pot Core)
Core Factor (ΣI/A) mm1	1.25
