ECS-80-18-5G3X-JGN-TR
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ECS-80-18-5G3X-JGN-TR with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ECS-80-18-5G3X-JGN-TR with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ECS-80-18-5G3X-JGN-TR |
|---|---|
| Manufacturer | ECS Inc. International |
| Description | CRYSTAL 8.000MHZ 18PF SMT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | 500 pcs |
|---|---|---|---|---|---|
| $0.204 | $0.17 | $0.153 | $0.136 | $0.129 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | ECS-80-18-5G3X-JGN-TR | Manufacturer | ECS Inc. International |
|---|---|---|---|
| Description | CRYSTAL 8.000MHZ 18PF SMT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 172534 pcs | Data sheet | CSM-7X-3L Series Datasheet |
| Category | Crystals, Oscillators, Resonators | Type | MHz Crystal |
| Size / Dimension | 0.449" L x 0.185" W (11.40mm x 4.70mm) | Series | CSM-7X-3L |
| Ratings | - | Packaging | Original-Reel® |
| Package / Case | HC-49/US | Other Names | XC2766DKR |
| Operating Temperature | -40°C ~ 85°C | Operating Mode | Fundamental |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 9 Weeks | Load Capacitance | 18pF |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 0.165" (4.20mm) |
| Frequency Tolerance | ±20ppm | Frequency Stability | ±30ppm |
| Frequency | 8MHz | ESR (Equivalent Series Resistance) | 70 Ohms |
| Detailed Description | 8MHz ±20ppm Crystal 18pF 70 Ohms HC-49/US |
