Home > Products > Switches > Tactile Switches > TL3253BRNBGNF160Q

TL3253BRNBGNF160Q

TL3253BRNBGNF160Q

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TL3253BRNBGNF160Q with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	TL3253BRNBGNF160Q
Manufacturer	E-Switch
Description	SWITCH TACTILE SPSTX2 0.05A 12V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 20469 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
Reference Price (In US Dollars)	$1.742	$1.66	$1.577	$1.536

Product parameter
Data sheet

Product parameter

Part Number	TL3253BRNBGNF160Q	Manufacturer	E-Switch
Description	SWITCH TACTILE SPSTX2 0.05A 12V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	20469 pcs	Data sheet	TL3253BRNBGNF160Q Drawing TL3253 Series Datasheet
Category	Switches	Termination Style	PC Pin
Switch Travel	0.25mm	Switch Function	Off-Mom
Series	TL3253	Packaging	Bulk
Outline	22.60mm x 8.40mm	Other Names	EG4991 TL3253BRNBGN160Q
Operating Temperature	-20°C ~ 70°C	Operating Force	160gf
Mounting Type	Through Hole, Right Angle	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	500,000 Cycles	Manufacturer Standard Lead Time	10 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Illumination Voltage (Nominal)	1.95, 2.1 VDC	Illumination Type, Color	LED, Red/Green
Illumination	Illuminated	Features	-
Detailed Description	Tactile Switch SPST x 2 Side Actuated Through Hole, Right Angle	Contact Rating @ Voltage	0.05A @ 12VDC
Circuit	SPST x 2	Actuator Type	Dual
Actuator Orientation	Side Actuated	Actuator Material	-
Actuator Length, Right Angle	8.55mm	Actuator Height off PCB, Vertical	-
