Home > Products > Switches > Pushbutton Switches > PV3F2H0NN-234

PV3F2H0NN-234

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PV3F2H0NN-234 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	PV3F2H0NN-234
Manufacturer	E-Switch
Description	SWITCH PUSHBUTTON DPDT 2A 48V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs
~~In Stock~~ 8288 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$5.132	$4.861	$4.793	$4.455
	$4.388	$3.915	$3.78

Product parameter
Data sheet

Product parameter

Part Number	PV3F2H0NN-234	Manufacturer	E-Switch
Description	SWITCH PUSHBUTTON DPDT 2A 48V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	8288 pcs	Data sheet	PV3 Series Datasheet
Category	Switches	Voltage Rating - DC	48V
Type	Vandal Resistant, Illuminated	Termination Style	Solder Lug
Switch Function	On-Mom	Series	PV3, LAMB
Panel Cutout Dimensions	Circular - 16.00mm Dia	Packaging	Bulk
Other Names	EG5203 PV3F2H0NN-234-ND	Operating Temperature	-20°C ~ 55°C
Mounting Type	Panel Mount, Front	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	1,000,000 Cycles	Manufacturer Standard Lead Time	9 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	IP40
Illumination Voltage (Nominal)	12 VDC	Illumination Type, Color	LED, Green
Features	-	Electrical Life	50,000 Cycles
Detailed Description	Pushbutton Switch DPDT Vandal Resistant, Illuminated Panel Mount, Front	Current Rating	2A (DC)
Color - Actuator/Cap	Silver	Circuit	DPDT
Actuator Type	Round, Button, Flush
