Home > Products > Switches > Snap Action, Limit Switches > LS0851505F250C1A

LS0851505F250C1A

LS0851505F250C1A

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LS0851505F250C1A with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	LS0851505F250C1A
Manufacturer	E-Switch
Description	SWITCH SNAP ACTION SPDT 15A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 86231 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
	$0.718	$0.678	$0.651	$0.624	$0.597
	$0.475	$0.434	$0.42	$0.38

Product parameter
Data sheet

Product parameter

Part Number	LS0851505F250C1A	Manufacturer	E-Switch
Description	SWITCH SNAP ACTION SPDT 15A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	86231 pcs	Data sheet	LS0851505F250C1A Drawing LS Series Datasheet
Category	Switches	Voltage Rating - AC	125V
Termination Style	Quick Connect - 0.187" (4.7mm)	Switch Function	On-Mom
Series	LS	Release Force	50gf
Pretravel	0.106" (2.7mm)	Packaging	Bulk
Overtravel	-	Other Names	EG4530
Operating Temperature	-25°C ~ 85°C	Operating Position	0.815" (20.7mm)
Operating Force	250gf	Mounting Type	Chassis Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	1,000,000 Cycles
Manufacturer Standard Lead Time	11 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Features	-
Electrical Life	50,000 Cycles	Differential Travel	-
Current Rating	15A (AC)	Circuit	SPDT
Actuator Type	Lever, Roller
