ZXMN2F34MATA
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ZXMN2F34MATA with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ZXMN2F34MATA with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ZXMN2F34MATA |
|---|---|
| Manufacturer | Diodes Incorporated |
| Description | MOSFET N-CH 20V 4A DFN-2X2 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ZXMN2F34MATA | Manufacturer | Diodes Incorporated |
|---|---|---|---|
| Description | MOSFET N-CH 20V 4A DFN-2X2 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5887 pcs | Data sheet | ZXMN2F34MA |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 1.5V @ 250µA |
| Vgs (Max) | ±12V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | DFN322 | Series | - |
| Rds On (Max) @ Id, Vgs | 60 mOhm @ 2.5A, 4.5V | Power Dissipation (Max) | 1.35W (Ta) |
| Packaging | Tape & Reel (TR) | Package / Case | 3-VDFN |
| Other Names | ZXMN2F34MATR | Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 277pF @ 10V |
| Gate Charge (Qg) (Max) @ Vgs | 2.8nC @ 4.5V | FET Type | N-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 4.5V |
| Drain to Source Voltage (Vdss) | 20V | Detailed Description | N-Channel 20V 4A (Ta) 1.35W (Ta) Surface Mount DFN322 |
| Current - Continuous Drain (Id) @ 25°C | 4A (Ta) |
