Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - Audio Amplifiers > ZXCD50STEVAL

ZXCD50STEVAL

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ZXCD50STEVAL with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	ZXCD50STEVAL
Manufacturer	Diodes Incorporated
Description	BOARD EVAL STEREO ANALOG CLASS D
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4384 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	ZXCD50STEVAL	Manufacturer	Diodes Incorporated
Description	BOARD EVAL STEREO ANALOG CLASS D	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4384 pcs	Data sheet	ZXCD50STEVAL
Category	Development Boards, Kits, Programmers	Voltage - Supply	13 V ~ 25 V
Utilized IC / Part	ZXCD1000	Supplied Contents	Board(s)
Series	Acoustar™	Output Type	2-Channel (Stereo)
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Max Output Power x Channels @ Load	50W x 2 @ 4 Ohm
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Detailed Description	ZXCD1000 Acoustar™ 2-Channel (Stereo) Output Class D Audio Amplifier Evaluation Board
Board Type	Fully Populated	Amplifier Type	Class D
