Home > Products > Discrete Semiconductor Products > Diodes - Rectifiers - Single > SBR12U45LH1-13R

SBR12U45LH1-13R

SBR12U45LH1-13R

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SBR12U45LH1-13R with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SBR12U45LH1-13R
Manufacturer	Diodes Incorporated
Description	DIODE SBR 45V 12A POWERDI5SP
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 82014 pcs
Reference Price (In US Dollars)	3000 pcs
Reference Price (In US Dollars)	$0.261

Product parameter
Data sheet

Product parameter

Part Number	SBR12U45LH1-13R	Manufacturer	Diodes Incorporated
Description	DIODE SBR 45V 12A POWERDI5SP	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	82014 pcs	Data sheet	SBR12U45LH1
Category	Discrete Semiconductor Products	Voltage - Forward (Vf) (Max) @ If	500mV @ 12A
Voltage - DC Reverse (Vr) (Max)	45V	Supplier Device Package	PowerDI5SP™
Speed	Standard Recovery >500ns, > 200mA (Io)	Series	SBR®
Packaging	Tape & Reel (TR)	Package / Case	PowerDI™ 5SP
Other Names	SBR12U45LH1-13RDITR	Operating Temperature - Junction	-65°C ~ 150°C
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	20 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Diode Type	Super Barrier	Detailed Description	Diode Super Barrier 45V 12A Surface Mount PowerDI5SP™
Current - Reverse Leakage @ Vr	300µA @ 45V	Current - Average Rectified (Io)	12A
Capacitance @ Vr, F	-
