DMN3025LFG-13
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DMN3025LFG-13 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DMN3025LFG-13 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DMN3025LFG-13 |
|---|---|
| Manufacturer | Diodes Incorporated |
| Description | MOSFET N-CH 30V 7.5A POWERDI |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | ||||
|---|---|---|---|---|---|
| $0.069 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | DMN3025LFG-13 | Manufacturer | Diodes Incorporated |
|---|---|---|---|
| Description | MOSFET N-CH 30V 7.5A POWERDI | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 333305 pcs | Data sheet | DMN3025LFG |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 2V @ 250µA |
| Vgs (Max) | ±20V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | PowerDI3333-8 | Series | - |
| Rds On (Max) @ Id, Vgs | 18 mOhm @ 7.8A, 10V | Power Dissipation (Max) | 2W (Ta) |
| Packaging | Tape & Reel (TR) | Package / Case | 8-PowerWDFN |
| Other Names | DMN3025LFG-13DI DMN3025LFG-13DI-ND DMN3025LFG-13DITR |
Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 32 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 605pF @ 15V | Gate Charge (Qg) (Max) @ Vgs | 11.6nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V | Drain to Source Voltage (Vdss) | 30V |
| Detailed Description | N-Channel 30V 7.5A (Ta) 2W (Ta) Surface Mount PowerDI3333-8 | Current - Continuous Drain (Id) @ 25°C | 7.5A (Ta) |
