Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - LED Drivers > AP8802HEV2

AP8802HEV2

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AP8802HEV2 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	AP8802HEV2
Manufacturer	Diodes Incorporated
Description	EVAL BOARD FOR AP8802H
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1871 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$20.748

Product parameter
Data sheet

Product parameter

Part Number	AP8802HEV2	Manufacturer	Diodes Incorporated
Description	EVAL BOARD FOR AP8802H	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1871 pcs	Data sheet	AP8802H AP8802HEV2 User Guide
Category	Development Boards, Kits, Programmers	Voltage - Output	-
Voltage - Input	8 V ~ 60 V	Utilized IC / Part	AP8802H
Supplied Contents	Board(s)	Series	-
Outputs and Type	1, Non-Isolated	Other Names	AP8802HEV2DI
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	10 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	Dimmable
Detailed Description	AP8802H 1, Non-Isolated Output LED Driver Evaluation Board	Current - Output / Channel	1A
