AP22815AWT-7
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AP22815AWT-7 with confidence from Components-World.HK, 1 Year Warranty
Dowload AP22815AWT-7 Details in PDFSee Product Specifications for product details.
Buy AP22815AWT-7 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AP22815AWT-7 |
|---|---|
| Manufacturer | Diodes Incorporated |
| Description | IC LOAD SWITCH TSOT25 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | 6000 pcs | 15000 pcs | 30000 pcs | |
|---|---|---|---|---|---|
| $0.12 | $0.112 | $0.108 | $0.103 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | AP22815AWT-7 | Manufacturer | Diodes Incorporated |
|---|---|---|---|
| Description | IC LOAD SWITCH TSOT25 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 200440 pcs | Data sheet | AP22815, AP22615 Datasheet |
| Category | Integrated Circuits (ICs) | Voltage - Supply (Vcc/Vdd) | 3 V ~ 5.5 V |
| Voltage - Load | 0 V ~ 23 V | Switch Type | USB Switch |
| Supplier Device Package | TSOT-25 | Series | - |
| Rds On (Typ) | 40 mOhm | Ratio - Input:Output | 1:1 |
| Packaging | Tape & Reel (TR) | Package / Case | SOT-23-5 Thin, TSOT-23-5 |
| Output Type | N/P-Channel | Output Configuration | High Side |
| Other Names | AP22815AWT-7DITR | Operating Temperature | -40°C ~ 85°C (TA) |
| Number of Outputs | 1 | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Interface | On/Off | Input Type | Non-Inverting |
| Features | Load Discharge, Status Flag | Fault Protection | Over Current, Over Temperature, Over Voltage, Short Circuit |
| Current - Output (Max) | 3A |
