PD01D0505A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PD01D0505A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PD01D0505A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PD01D0505A |
|---|---|
| Manufacturer | Delta Electronics |
| Description | DC DC CONVERTER +/-5V 1W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $1.976 | $1.948 | $1.92 | $1.863 | ||
| 50 pcs | 100 pcs | 250 pcs | 500 pcs | ||
| $1.807 | $1.75 | $1.694 | $1.581 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PD01D0505A | Manufacturer | Delta Electronics |
|---|---|---|---|
| Description | DC DC CONVERTER +/-5V 1W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 23238 pcs | Data sheet | PD01(D,S) Series |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -5V | Voltage - Output 1 | 5V |
| Voltage - Isolation | 3kV | Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 5.5V | Type | Isolated Module |
| Size / Dimension | 0.77" L x 0.24" W x 0.40" H (19.6mm x 6.0mm x 10.2mm) | Series | PD01S/D |
| Power (Watts) | 1W | Packaging | Tube |
| Package / Case | 7-SIP Module, 5 Leads | Other Names | 941-1128 |
| Operating Temperature | -40°C ~ 85°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 24 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | SCP | Efficiency | 72% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 5V -5V 100mA, 100mA 4.5V - 5.5V Input | Current - Output (Max) | 100mA, 100mA |
| Applications | Medical |
