DB02S0503A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DB02S0503A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DB02S0503A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DB02S0503A |
|---|---|
| Manufacturer | Delta Electronics |
| Description | DC DC CONVERTER 3.3V 2W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $3.755 | $3.727 | $3.699 | $3.642 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | DB02S0503A | Manufacturer | Delta Electronics |
|---|---|---|---|
| Description | DC DC CONVERTER 3.3V 2W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 8542 pcs | Data sheet | DB02(D,S) Series |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | - | Voltage - Output 1 | 3.3V |
| Voltage - Isolation | 1.5kV | Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 9V | Type | Isolated Module |
| Size / Dimension | 0.94" L x 0.54" W x 0.30" H (23.9mm x 13.7mm x 7.5mm) | Series | DB02S/D |
| Power (Watts) | 2W | Packaging | Tube |
| Package / Case | 16-DIP Module, 6 Leads | Other Names | 941-1395 |
| Operating Temperature | -40°C ~ 80°C | Number of Outputs | 1 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | SCP, UVLO |
| Efficiency | 70% | Detailed Description | Isolated Module DC DC Converter 1 Output 3.3V 500mA 4.5V - 9V Input |
| Current - Output (Max) | 500mA | Applications | Medical |
