RCWL0805R100JMEA
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RCWL0805R100JMEA with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RCWL0805R100JMEA with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RCWL0805R100JMEA |
|---|---|
| Manufacturer | Dale / Vishay |
| Description | RES 0.1 OHM 5% 1/8W 0805 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 5000 pcs | 10000 pcs | 25000 pcs | 50000 pcs | |
|---|---|---|---|---|---|
| $0.058 | $0.056 | $0.055 | $0.054 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | RCWL0805R100JMEA | Manufacturer | Dale / Vishay |
|---|---|---|---|
| Description | RES 0.1 OHM 5% 1/8W 0805 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 444554 pcs | Data sheet | RCWL Series Datasheet |
| Category | Resistors | Tolerance | ±5% |
| Temperature Coefficient | ±300ppm/°C | Supplier Device Package | 0805 |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | Series | RCWL |
| Resistance | 100 mOhms | Power (Watts) | 0.125W, 1/8W |
| Packaging | Tape & Reel (TR) | Package / Case | 0805 (2012 Metric) |
| Operating Temperature | -55°C ~ 155°C | Number of Terminations | 2 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 26 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 0.020" (0.50mm) |
| Features | Automotive AEC-Q200, Current Sense, Moisture Resistant | Failure Rate | - |
| Detailed Description | 100 mOhms ±5% 0.125W, 1/8W Chip Resistor 0805 (2012 Metric) Automotive AEC-Q200, Current Sense, Moisture Resistant Thick Film | Composition | Thick Film |
