IHLP3232CZER220M11
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy IHLP3232CZER220M11 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy IHLP3232CZER220M11 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | IHLP3232CZER220M11 |
|---|---|
| Manufacturer | Dale / Vishay |
| Description | FIXED IND 22UH 3.6A 132 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | 3000 pcs | 5000 pcs | 10000 pcs | |
|---|---|---|---|---|---|
| $0.26 | $0.252 | $0.244 | $0.235 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | IHLP3232CZER220M11 | Manufacturer | Dale / Vishay |
|---|---|---|---|
| Description | FIXED IND 22UH 3.6A 132 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 89971 pcs | Data sheet | IHLP-3232CZ-11 Series Datasheet |
| Category | Inductors, Coils, Chokes | Type | Molded |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.340" L x 0.322" W (8.64mm x 8.18mm) | Shielding | Shielded |
| Series | IHLP-3232CZ-11 | Ratings | - |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | 541-4348-2 IHLP3232CZER220M11-ND |
| Operating Temperature | -55°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 100kHz |
| Inductance | 22µH | Height - Seated (Max) | 0.118" (3.00mm) |
| Frequency - Self Resonant | 7.7MHz | Detailed Description | 22µH Shielded Molded Inductor 3.6A 132 mOhm Max Nonstandard |
| DC Resistance (DCR) | 132 mOhm Max | Current Rating | 3.6A |
| Current - Saturation | 2.8A |
