M505012F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy M505012F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy M505012F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | M505012F |
|---|---|
| Manufacturer | Crydom |
| Description | MODULE POWER 50A 600V SCR DIODE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $28.022 | $26.703 | $25.475 | $24.732 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | M505012F | Manufacturer | Crydom |
|---|---|---|---|
| Description | MODULE POWER 50A 600V SCR DIODE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1533 pcs | Data sheet | M50 SeriesM50 Series, Circuit 1,2,4,5,6 & 7 DrawingSolid State Power Switching Brochure |
| Category | Discrete Semiconductor Products | Voltage - Off State | 600V |
| Voltage - Gate Trigger (Vgt) (Max) | 3V | Structure | Bridge, Single Phase - SCRs/Diodes (Layout 1) |
| Series | - | Packaging | Bulk |
| Package / Case | Module | Other Names | CC1654 M505012F-ND |
| Operating Temperature | -40°C ~ 125°C (TJ) | Number of SCRs, Diodes | 2 SCRs, 2 Diodes |
| Mounting Type | Chassis Mount | Manufacturer Standard Lead Time | 6 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Detailed Description | SCR Module 600V Bridge, Single Phase - SCRs/Diodes (Layout 1) Chassis Mount Module |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 600A @ 60Hz | Current - Gate Trigger (Igt) (Max) | 150mA |
