Home > Products > Discrete Semiconductor Products > Thyristors - SCRs - Modules > L514F

L514F

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy L514F with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	L514F
Manufacturer	Crydom
Description	MODULE SCR/DIODE 25A 480VAC PCB
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1514 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	50 pcs	100 pcs
Reference Price (In US Dollars)	$27.585	$26.289	$25.08	$24.351

Product parameter
Data sheet

Product parameter

Part Number	L514F	Manufacturer	Crydom
Description	MODULE SCR/DIODE 25A 480VAC PCB	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1514 pcs	Data sheet	L Series Solid State Power Switching Brochure
Category	Discrete Semiconductor Products	Voltage - Off State	1.2kV
Voltage - Gate Trigger (Vgt) (Max)	3V	Structure	Bridge, Single Phase - SCRs/Diodes (Layout 1)
Series	-	Packaging	Bulk
Package / Case	Module	Other Names	CC1926 L514F-ND
Operating Temperature	-40°C ~ 125°C (TJ)	Number of SCRs, Diodes	2 SCRs, 2 Diodes
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Detailed Description	SCR Module 1.2kV Bridge, Single Phase - SCRs/Diodes (Layout 1) Through Hole Module
Current - Non Rep. Surge 50, 60Hz (Itsm)	300A @ 60Hz	Current - Gate Trigger (Igt) (Max)	100mA
