Home > Products > Discrete Semiconductor Products > Thyristors - SCRs - Modules > L321F

L321F

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy L321F with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	L321F
Manufacturer	Crydom
Description	MODULE SCR/DIODE 15A 120VAC PCB
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 2018 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	50 pcs	100 pcs
Reference Price (In US Dollars)	$17.734	$16.902	$16.124	$15.652

Product parameter
Data sheet

Product parameter

Part Number	L321F	Manufacturer	Crydom
Description	MODULE SCR/DIODE 15A 120VAC PCB	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	2018 pcs	Data sheet	L Series Solid State Power Switching Brochure
Category	Discrete Semiconductor Products	Voltage - Off State	400V
Voltage - Gate Trigger (Vgt) (Max)	2.5V	Structure	Bridge, Single Phase - SCRs/Diodes (Layout 2)
Series	-	Packaging	Bulk
Package / Case	Module	Other Names	CC2354 L321F-ND
Operating Temperature	-40°C ~ 125°C (TJ)	Number of SCRs, Diodes	2 SCRs, 2 Diodes
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	7 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Detailed Description	SCR Module 400V Bridge, Single Phase - SCRs/Diodes (Layout 2) Through Hole Module	Current - Non Rep. Surge 50, 60Hz (Itsm)	2250A @ 60Hz
Current - Gate Trigger (Igt) (Max)	100mA
