Home > Products > Discrete Semiconductor Products > Thyristors - SCRs - Modules > L313

L313

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy L313 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	L313
Manufacturer	Crydom
Description	MODULE SCR/DIODE 15A 280VAC PCB
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1239 pcs
Reference Price (In US Dollars)	5 pcs
Reference Price (In US Dollars)	$24.415

Product parameter
Data sheet

Product parameter

Part Number	L313	Manufacturer	Crydom
Description	MODULE SCR/DIODE 15A 280VAC PCB	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1239 pcs	Data sheet	L Series Solid State Power Switching Brochure
Category	Discrete Semiconductor Products	Voltage - Off State	800V
Voltage - Gate Trigger (Vgt) (Max)	2.5V	Structure	Bridge, Single Phase - SCRs/Diodes (Layout 1)
Series	-	Packaging	Bulk
Package / Case	Module	Operating Temperature	-40°C ~ 125°C (TJ)
Number of SCRs, Diodes	2 SCRs, 2 Diodes	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Detailed Description	SCR Module 800V Bridge, Single Phase - SCRs/Diodes (Layout 1) Through Hole Module	Current - Non Rep. Surge 50, 60Hz (Itsm)	2250A @ 60Hz
Current - Gate Trigger (Igt) (Max)	100mA
