ZUW30515
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ZUW30515 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ZUW30515 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ZUW30515 |
|---|---|
| Manufacturer | Cosel |
| Description | DC DC CONVERTER +/-15V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $8.878 | $8.81 | $8.741 | $8.604 | ||
| 50 pcs | 100 pcs | 250 pcs | |||
| $8.195 | $7.512 | $7.375 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | ZUW30515 | Manufacturer | Cosel |
|---|---|---|---|
| Description | DC DC CONVERTER +/-15V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4144 pcs | Data sheet | ZUW Series Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -15V | Voltage - Output 1 | 15V |
| Voltage - Isolation | 500V | Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 9V | Type | Isolated Module |
| Supplier Device Package | - | Size / Dimension | 1.38" L x 0.91" W x 0.28" H (35.0mm x 23.0mm x 7.0mm) |
| Series | ZUW | Packaging | - |
| Package / Case | 5-DIP Module | Other Names | 1776-1914 |
| Operating Temperature | -20°C ~ 71°C (With Derating) | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | Not Applicable |
| Manufacturer Standard Lead Time | 22 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | OCP | Efficiency | 70% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 15V -15V 100mA, 100mA 4.5V - 9V Input | Current - Output (Max) | 100mA, 100mA |
| Applications | ITE (Commercial) |
