TY3F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TY3F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TY3F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TY3F |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN PLUG FM MINI XLR 3P SDR CUP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $10.601 | $9.57 | $9.169 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $8.596 | $8.309 | $7.851 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | TY3F | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN PLUG FM MINI XLR 3P SDR CUP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3993 pcs | Data sheet | TYxF Series Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 125VAC |
| Termination | Solder Cup | Shielding | - |
| Shell Size, MIL | - | Shell Size - Insert | Mini XLR |
| Shell Material | Brass | Shell Finish | Nickel |
| Series | TINI Q-G® TY | Packaging | Bulk |
| Other Names | SC2577 TY3F-ND |
Orientation | Keyed |
| Operating Temperature | -55°C ~ 85°C | Number of Positions | 3 |
| Mounting Type | Panel Mount | Mounting Feature | Flange |
| Material Flammability Rating | - | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insert Material | Polyphenylene Sulfide (PPS) |
| Ingress Protection | - | Features | Ground |
| Fastening Type | Latch Lock | Detailed Description | 3 Position Circular Connector Plug, Female Sockets Solder Cup Silver |
| Current Rating | 5A | Contact Material | Beryllium Copper |
| Contact Finish Thickness - Mating | - | Contact Finish - Mating | Silver |
| Connector Type | Plug, Female Sockets | Color | Silver |
| Cable Opening | - | Backshell Material, Plating | - |
| Applications | Audio |
