TR2A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TR2A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TR2A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TR2A |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN JACK MONO 2.46MM PNL MNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.194 | $1.10 | $1.038 | $1.006 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $0.959 | $0.943 | $0.925 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | TR2A | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN JACK MONO 2.46MM PNL MNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 42224 pcs | Data sheet | TR2A Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Thread Size | #10-48 | Termination | Solder Eyelet(s) |
| Signal Lines | Mono | Shielding | Unshielded |
| Series | Micro-Jax® | Panel Hole Size | 0.190" (4.83mm) |
| Packaging | Bulk | Other Names | SC1514 TR2A-ND |
| Operating Temperature | -20°C ~ 65°C | Number of Positions/Contacts | 2 Conductors, 3 Contacts |
| Mounting Type | Panel Mount | Moisture Sensitivity Level (MSL) | Not Applicable |
| Mating Length/Depth | - | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Internal Switch(s) | Single Switch |
| Insulation Color | - | Industry Recognized Mating Diameter | 2.46mm ID (0.097") |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer | Housing Material | - |
| Gender | Female | Features | Mounting Hardware, Thread Lock |
| Detailed Description | 2.46mm ID (0.097") Phone Jack Mono Connector Solder Eyelet(s) | Contact Material - Plating | Silver |
| Contact Material | Copper Alloy | Connector Type | Phone Jack |
| Cable Opening | - | Body Material | Copper Alloy |
| Body Color | Black | Actual Diameter | 0.101" (2.57mm) |
