S12B
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy S12B with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy S12B with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | S12B |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN JACK STEREO 5.23MM PNL MNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.199 | $1.104 | $1.04 | $1.009 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $0.962 | $0.946 | $0.927 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | S12B | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN JACK STEREO 5.23MM PNL MNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 38736 pcs | Data sheet | 1/4" Phone JacksS12B Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | 25VDC |
| Thread Size | 3/8"-32 | Termination | Solder Eyelet(s) |
| Signal Lines | Stereo (3 Conductor, TRS) | Shielding | Unshielded |
| Series | LITTEL-JAX® | Panel Hole Size | 0.375" (9.52mm) |
| Packaging | Bulk | Other Names | SC1097 |
| Operating Temperature | -20°C ~ 65°C | Number of Positions/Contacts | 3 Conductors, 3 Contacts |
| Mounting Type | Panel Mount, Through Hole | Moisture Sensitivity Level (MSL) | Not Applicable |
| Mating Length/Depth | - | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Internal Switch(s) | Does Not Contain Switch |
| Insulation Color | - | Industry Recognized Mating Diameter | 5.23mm (0.206") |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer | Housing Material | - |
| Gender | Female | Features | Mounting Hardware, Thread Lock |
| Detailed Description | 5.23mm (0.206") Phone Jack Stereo (3 Conductor, TRS) Connector Solder Eyelet(s) | Current Rating | 1A |
| Contact Material - Plating | Natural | Contact Material | Copper Alloy |
| Connector Type | Phone Jack | Cable Opening | - |
| Body Material | Copper Alloy | Body Color | Silver |
| Actual Diameter | 0.210" (5.33mm) |
