S11
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy S11 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy S11 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | S11 |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN JACK MONO 5.23MM PNL MNT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.542 | $1.247 | $1.143 | $1.091 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.039 | $0.909 | $0.883 | $0.844 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | S11 | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN JACK MONO 5.23MM PNL MNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 45305 pcs | Data sheet | S11 Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | 25VDC |
| Thread Size | - | Termination | Solder Eyelet(s) |
| Signal Lines | Mono | Shielding | Unshielded |
| Series | LITTEL-JAX® | Panel Hole Size | - |
| Packaging | Bulk | Other Names | SC1088 |
| Operating Temperature | -20°C ~ 65°C | Number of Positions/Contacts | 2 Conductors, 2 Contacts |
| Mounting Type | Panel Mount | Moisture Sensitivity Level (MSL) | Not Applicable |
| Mating Length/Depth | - | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Internal Switch(s) | Does Not Contain Switch |
| Insulation Color | - | Industry Recognized Mating Diameter | 5.23mm (0.206") |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer | Housing Material | - |
| Gender | Female | Features | Mounting Hardware, Thread Lock |
| Detailed Description | 5.23mm (0.206") Phone Jack Mono Connector Solder Eyelet(s) | Current Rating | 1A |
| Contact Material - Plating | - | Contact Material | Copper Alloy |
| Connector Type | Phone Jack | Cable Opening | - |
| Body Material | Copper Alloy | Body Color | Silver |
| Actual Diameter | 0.210" (5.33mm) |
