Home > Products > Connectors, Interconnects > Barrel - Audio Connectors > MDSL2A

MDSL2A

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MDSL2A with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MDSL2A
Manufacturer	Conxall / Switchcraft
Description	CONN JACK MONO 2.46MM PNL MNT
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	50 pcs	100 pcs	250 pcs
~~In Stock~~ 55975 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs
	$0.844	$0.683	$0.626
	$0.598	$0.569	$0.556

Product parameter
Data sheet

Product parameter

Part Number	MDSL2A	Manufacturer	Conxall / Switchcraft
Description	CONN JACK MONO 2.46MM PNL MNT	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	55975 pcs	Data sheet	MDSL2A Drawing
Category	Connectors, Interconnects	Voltage - Rated	-
Thread Size	#10-48	Termination	Solder Eyelet(s)
Signal Lines	Mono	Shielding	Unshielded
Series	Micro-D JAX®	Panel Hole Size	-
Packaging	Bulk	Other Names	SC1043
Operating Temperature	-20°C ~ 65°C	Number of Positions/Contacts	2 Conductors, 3 Contacts
Mounting Type	Panel Mount, Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mating Length/Depth	-	Manufacturer Standard Lead Time	12 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Internal Switch(s)	Single Switch
Insulation Color	-	Industry Recognized Mating Diameter	2.46mm ID (0.097")
Includes	3 pcs - 1 Connector, 1 Nut, 1 Washer	Housing Material	Plastic
Gender	Female	Features	Mounting Hardware, Thread Lock
Detailed Description	2.46mm ID (0.097") Phone Jack Mono Connector Solder Eyelet(s)	Contact Material - Plating	Nickel
Contact Material	Copper Alloy	Connector Type	Phone Jack
Cable Opening	-	Body Material	-
Body Color	Black	Actual Diameter	0.101" (2.57mm)
