E3MSC
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy E3MSC with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy E3MSC with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | E3MSC |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN RCPT MALE XLR 3POS SLDR CUP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $1.895 | $1.82 | $1.668 | $1.592 | $1.517 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $1.327 | $1.289 | $1.099 | $1.024 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | E3MSC | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN RCPT MALE XLR 3POS SLDR CUP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 34337 pcs | Data sheet | E Series ReceptaclesEH Series, QG Panels Product Bulletin |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder Cup | Shielding | Shielded |
| Shell Size, MIL | - | Shell Size - Insert | XLR |
| Shell Material | Zinc Die Cast | Shell Finish | Nickel |
| Series | Q-G® E | Packaging | Bulk |
| Other Names | E3MSC-ND SC2465 |
Orientation | Keyed |
| Operating Temperature | -55°C ~ 85°C | Number of Positions | 3 |
| Mounting Type | Panel Mount | Mounting Feature | Flange |
| Material Flammability Rating | - | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insert Material | Thermoplastic |
| Ingress Protection | - | Features | Ground |
| Fastening Type | Latch Lock | Detailed Description | 3 Position Circular Connector Receptacle, Male Pins Solder Cup Silver |
| Current Rating | 15A | Contact Material | Copper Alloy |
| Contact Finish Thickness - Mating | - | Contact Finish - Mating | Silver |
| Connector Type | Receptacle, Male Pins | Color | Silver |
| Cable Opening | - | Backshell Material, Plating | - |
| Applications | Audio, Instrumentation |
