838
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 838 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 838 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 838 |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN JACK STEREO 6.35MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $4.393 | $3.362 | $3.278 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $3.026 | $2.858 | $2.731 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 838 | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN JACK STEREO 6.35MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 11057 pcs | Data sheet | Jack Schematics838 Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Thread Size | - | Termination | Solder Eyelet(s) |
| Signal Lines | Stereo (3 Conductor, TRS) | Shielding | Unshielded |
| Series | Extension Jax® | Panel Hole Size | - |
| Packaging | Bulk | Other Names | 838-ND 838S 838S-ND Q996764 SC2735 |
| Operating Temperature | - | Number of Positions/Contacts | 3 Conductors, 3 Contacts |
| Mounting Type | Free Hanging (In-Line) | Mating Length/Depth | - |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Internal Switch(s) | Does Not Contain Switch | Insulation Color | Silver |
| Industry Recognized Mating Diameter | 6.35mm (0.250", 1/4") - Headphone | Includes | 2 pcs - 1 Connector, 1 Handle |
| Housing Material | Polyamide (PA), Nylon | Gender | Female |
| Features | - | Detailed Description | 6.35mm (0.250", 1/4") - Headphone Phone Jack Stereo (3 Conductor, TRS) Connector Solder Eyelet(s) |
| Contact Material - Plating | Nickel | Contact Material | Brass |
| Connector Type | Phone Jack | Cable Opening | 0.281" (7.14mm) |
| Body Material | Brass | Body Color | Silver, Black |
| Actual Diameter | 0.255" (6.48mm) |
