35HDLBAUS
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 35HDLBAUS with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 35HDLBAUS with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 35HDLBAUS |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN PLUG STEREO 3.5MM 3COND |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $4.29 | $3.284 | $3.202 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $2.956 | $2.792 | $2.669 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 35HDLBAUS | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN PLUG STEREO 3.5MM 3COND | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 13437 pcs | Data sheet | 35HDL Series Datasheet |
| Category | Connectors, Interconnects | Voltage - Rated | 250VAC, 140VDC |
| Thread Size | - | Termination | Solder Eyelet(s) |
| Signal Lines | Stereo (3 Conductor, TRS) | Shielding | Unshielded |
| Series | 35HD | Panel Hole Size | - |
| Packaging | Bulk | Other Names | SC1485 |
| Operating Temperature | -20°C ~ 85°C | Number of Positions/Contacts | 3 Conductors, 3 Contacts |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Length/Depth | 0.560" (14.20mm) | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Internal Switch(s) | - |
| Insulation Color | - | Industry Recognized Mating Diameter | 3.50mm (0.141", 1/8", Mini Plug) - Headphone |
| Includes | 3 pcs - 1 Connector, 1 Handle, 1 Insulator Tube | Housing Material | Copper Alloy |
| Gender | Male | Features | - |
| Detailed Description | 3.50mm (0.141", 1/8", Mini Plug) - Headphone Phone Plug Stereo (3 Conductor, TRS) Connector Solder Eyelet(s) | Current Rating | 4A |
| Contact Material - Plating | Gold | Contact Material | Copper Alloy |
| Connector Type | Phone Plug | Cable Opening | 0.175" (4.44mm) |
| Body Material | Copper Alloy | Body Color | Gold, Black |
| Actual Diameter | 0.139" (3.53mm) |
