3503X
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 3503X with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 3503X with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 3503X |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN RCA JACK MONO 3.2MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.453 | $1.175 | $1.077 | $1.028 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $0.979 | $0.857 | $0.85 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 3503X | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN RCA JACK MONO 3.2MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 41880 pcs | Data sheet | Phono Jacks3503X Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Thread Size | - | Termination | Solder Cup |
| Signal Lines | Mono | Shielding | Shielded |
| Series | - | Panel Hole Size | - |
| Packaging | Bulk | Other Names | SC1323 |
| Operating Temperature | - | Number of Positions/Contacts | 2 Conductors, 2 Contacts |
| Mounting Type | Free Hanging (In-Line) | Mating Length/Depth | - |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Internal Switch(s) | Does Not Contain Switch | Insulation Color | Black |
| Industry Recognized Mating Diameter | 3.20mm ID, 9.00mm OD (RCA) | Includes | 2 pcs - 1 Connector, 1 Handle |
| Housing Material | - | Gender | Female |
| Features | Mounting Hardware | Detailed Description | 3.20mm ID, 9.00mm OD (RCA) Phono (RCA) Jack Mono Connector Solder Cup |
| Contact Material - Plating | Nickel | Contact Material | Brass |
| Connector Type | Phono (RCA) Jack | Cable Opening | 0.200" (5.08mm) |
| Body Material | Brass | Body Color | Silver |
| Actual Diameter | - |
