238X
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 238X with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 238X with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 238X |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN PLUG STEREO 6.35MM RA 3COND |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $3.175 | $2.558 | $2.326 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $2.209 | $2.151 | $2.019 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 238X | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN PLUG STEREO 6.35MM RA 3COND | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17703 pcs | Data sheet | 238(X) Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Thread Size | - | Termination | Solder |
| Signal Lines | Stereo (3 Conductor, TRS) | Shielding | Shielded |
| Series | 230 | Panel Hole Size | - |
| Packaging | Bulk | Other Names | SC1314 |
| Operating Temperature | -20°C ~ 65°C | Number of Positions/Contacts | 3 Conductors, 3 Contacts |
| Mounting Type | Free Hanging (In-Line), Right Angle | Mating Length/Depth | 1.200" (30.50mm) |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Internal Switch(s) | Does Not Contain Switch | Insulation Color | - |
| Industry Recognized Mating Diameter | 6.35mm (0.250", 1/4") - Headphone | Includes | 4 pcs - 1 Connector, 1 Handle, 2 Screws |
| Housing Material | - | Gender | Male |
| Features | - | Detailed Description | 6.35mm (0.250", 1/4") - Headphone Phone Plug Stereo (3 Conductor, TRS) Connector Solder |
| Contact Material - Plating | Nickel | Contact Material | Brass |
| Connector Type | Phone Plug | Cable Opening | - |
| Body Material | Steel | Body Color | Silver |
| Actual Diameter | 0.250" (6.35mm) |
