Home > Products > Connectors, Interconnects > D-Sub Connectors > 164A18189X

164A18189X

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 164A18189X with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	164A18189X
Manufacturer	Conec
Description	CONN DSUB HD RCPT 26POS R/A SLDR
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs
~~In Stock~~ 7706 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$6.555	$6.087	$5.462	$5.306
	$4.682	$4.37	$4.276

Product parameter
Data sheet

Product parameter

Part Number	164A18189X	Manufacturer	Conec
Description	CONN DSUB HD RCPT 26POS R/A SLDR	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	7706 pcs	Data sheet	164A18xx9X Drawing
Category	Connectors, Interconnects	Wire Gauge	-
Voltage Rating	60V	Termination	Solder
Shell Size, Connector Layout	2 (DA, A) High Density	Shell Material, Finish	Steel, Tin Plated
Series	164A	Packaging	Bulk
Other Names	164A18189X-ND 626-2215 Q4545107B	Operating Temperature	-55°C ~ 125°C
Number of Rows	3	Number of Positions	26
Mounting Type	Board Edge, Through Hole, Right Angle	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Manufacturer Standard Lead Time	12 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	IP20
Housing Material	Polybutylene Terephthalate (PBT), Glass Filled	Flange Feature	Housing/Shell (4-40)
Features	Board Lock	Detailed Description	26 Position D-Sub, High Density Receptacle, Female Sockets Connector
Current Rating	3A	Contact Type	Signal
Contact Material	Copper Alloy	Contact Form	Machined
Contact Finish Thickness	8.00µin (0.203µm)	Contact Finish	Gold
Connector Type	Receptacle, Female Sockets	Connector Style	D-Sub, High Density
Color	Black	Backset Spacing	0.314" (7.98mm)
