Home > Products > Switches > Rocker Switches > SRJ24A3HBBNN

SRJ24A3HBBNN

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SRJ24A3HBBNN with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SRJ24A3HBBNN
Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH ROCKER SPDT 20A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 89885 pcs
Reference Price (In US Dollars)	1000 pcs
Reference Price (In US Dollars)	$0.403

Product parameter
Data sheet

Product parameter

Part Number	SRJ24A3HBBNN	Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH ROCKER SPDT 20A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	89885 pcs	Data sheet	SRJ Series Datasheet
Category	Switches	Voltage Rating - AC	125V
Termination Style	Quick Connect - 0.187" (4.7mm)	Switch Function	On-Off-On
Series	SR	Panel Cutout Dimensions	Circular - 20.00mm Dia
Packaging	Bulk	Other Names	CH878
Operating Temperature	-20°C ~ 65°C	Mounting Type	Panel Mount, Snap-In
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	50,000 Cycles
Manufacturer Standard Lead Time	18 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Illumination Voltage (Nominal)	-
Illumination Type, Color	-	Features	-
Electrical Life	6,000 Cycles	Detailed Description	Rocker Switch SPDT 20A (AC) 125V Panel Mount, Snap-In
Current Rating	20A (AC)	Color - Actuator/Cap	Black
Circuit	SPDT	Actuator Type	Round
Actuator Marking	I O II
